Set aside six of the 68-inch pipes to use for the canopy’s legs. Begin joining the 52-inch and 68-inch pipes by inserting the male end of the 52-inch pipe into the female end of the 68-inch pipe.
It is best to begin attaching the pipes beginning with the center of your canopy’s frame. Begin by inserting your pipes into one 3-way corner to form the end of your center frame. The other side of this set of pipes should be connected to one end of a 4-way corner. Insert another set of pipes into the opposite end of the 4-way corner, capping it off with a 3-way corner. From each of your 3-way corners, you should now attach a 68-inch pipe into each side. Insert another 3-way corner into the ends of your 68-inch pipes; this forms the corners of your canopy. From this point, attach another set of joined pipes into your canopy corners to begin forming the sides of your canopy. Each set of joined pipes should be attached in the middle of the side by a 4-way corner. After you have finished this, you will simply need two more 68-inch pipes, and each needs to be inserted from the 4-way corner in the side’s center and joined at the center of the canopy.
